| Daya ( Kompesor ) : 1 PK ( Rotary ) : ½ PK Sistem : Rotary dan Pneumatik Lubang : 18 lubang Kapasitas : 5 detik / botol : 12.960 botol / jam |
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
SHRINK PACKAGING
Fungsi : membungkus kemasan (sistem press) dengan menggunkan heater listrik
Model : BS 350
Power supply : 220 – 240 V / 50 Hz
Heater power : KW Adjustable
Conveyor speed : 0 – 10 m / min
Tunnel size : 70 x 35 x 15 cm
Shrink product size : 300 x 150 mm
Conveyor loading : 5 kg Maximun
Tunnel temperature : 200 C Maximum
Machine size : 105 x 55 x 110 cm
Machine weight : 80 kg
Model : BS 400
Ukuran Tunnel : 83 x 40 x 20
Power supply : 220 – 240 V / 50 Hz
Heater power : 6.5KW Adjustable
Conveyor speed : 0 – 10 m / min
Tunnel size : 83 x 40 x 20 cm
Shrink product size : 350 x 150 mm
Conveyor loading : 5 kg Maximun
Tunnel temperature : 200 C Maximum
Machine size : 120 x 60 x 78.5 cm
Machine weight : 80 kg
Power Supply : 380 – 415 V / 50 Hz
Heater Power : 8 KW Adjustable
Conveyor Speed : 0 – 10 m / min
Tunnel Size : 83 x 45 x 25 cm
Shrink product size : 400 x 200 mm
Conveyor Loading : 10 kg Maximum
Tunnel temperature : 200 C Maximum
Machine Size : 120 x 69 x 120 cm
Machine Weight : 100 kg
CV.GRAHA MESIN GLOBALINDO
Produsen Mesin Usaha & Supplier Mesin Import
Mesin untuk mengemas packing gelas minuman yang biasa untuk es, cock tail, dan minuman lain yang biasa di jual di mall, restoran. Dioperasikan secara semi otomatis, sehingga sangat mudah dan efisien. Mesin ini sangat cocok untuk usaha franchise
–
Spesifikasi Mesin
Model : FRG 2001 B
Power supply : 220 – 240 V/50-60 Hz 1 Phase
Power consumption : 300 W
Sealing speed : 400 – 500 cup / hari
Machine size : 450 x 490 x 700 mm
Machine weight : 40 kg
Model : FRG 2001 C
Power supply : 220 – 240 V/50-60 Hz 1 Phase
Power consumption : 300 W
Sealing speed : 400 – 500 cup / hari
Machine size : 450 x 490 x 700 mm
Machine weight : 40 kg
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
Spesifikasi Mesin
| Model : DK-50/Z Power supply : 110 V 220V/ 50~60Hz Power : 0.37 KW Diameter suitable : 20-40mm Sealing width : 10-35mm Height and bottle : 100-300mm Sealing speed : 1200 Bottle/hr Type of cover : Plastic cover Machine size : 560 x 200 x 920mm Machine weigh : 65kgs Model : DK-50/D |
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
Spesifikasi Mesin
| Model : KZB – I Strapping Tension : 5 – 60 kgs Strapping Speed : 2.2 Sec. / Strap Strap Width : 6 – 15 mm Power Supply : 110 V, 220 V – 240 V Power Consumption : 50 – 60 Hz , 1 Phase Machine Size : 895 x 580 x 730 mm Machine Weight : 90 kg Model : KZB – II |
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
Mesin dirancang beroperasional 24 jam dan rapi serta suku cadangnya dipoduksi dengan alat ukur dan mesin-mesin komputerisasi dengan akurasi yang tinggi. Pengendalian volume takaran ini bisa diatur mesin akan berhenti apabila film habis, pengendalian panas yang sangat akurat.
1. AW 6035-SR
aw 6035 sr Mesin Pengemas Makanan Ringan Vertical Filling AW 6035 sr
Product : Powder, Seed, Granule, Chips etc.
Seal Tape : Centre seal ( pillow pack)
Machine Type : Vertical pouch with fix bag former size and volumetric cup system
Seal Dimension : W : 50-140 mm, L : 50 – 160 mm
Product Weight : Up to 250 gram
Machine Dimension : W x L x H = ( 670 x 6000 x 1770 ) mm
Packaging Material : AL + PE, OPP + PE, NY + PE and other sealable papers
Operating Speed : 40 – 120 pack/minute
Supply Voltage : 220/380, 1ph/3ph, Neutral 50 Hz/60 Hz
Power Requerement : 1.4 kVA
2. AW 6035-3ss
aw 6035 3ss1 138×300 Mesin Pengemas Makanan Ringan Vertical Filling AW 6035 sr
Product : Powder, Seed, Granule etc
Seal Type : Three side seal
Machine Type : Vertical sachet with fix bag former size and volumetric cup system
Seal Dimension : W : 50-100 mm, L : 50-140 mm
Product Weight : Up to 50 gram
Machine Dimension : W x L x H = (670 x 600 x 1770)mm
Packaging Material : AL + PE, OPP + PE, NY + PE and other sealable papers
Operating Speed : 40-80 packs/minute
Supply Voltage : 220/380, 1ph/3ph, neutral 50 Hz/60 Hz
Power Requirement : 1.4 kVA
3. AW 6035-4ss
aw 6035 4ss1 Mesin Pengemas Makanan Ringan Vertical Filling AW 6035 sr
Product : Powder, Seed, Granule etc
Seal Type : Four side seal
Machine Type : Vertical sachet with fix bag former size and volumetric cup system
Seal Dimension : W : 50-100 mm, L : 50-140 mm
Product Weight : Up to 50 gram
Machine Dimension : W x L x H = (670 x 600 x 1770)mm
Packaging Material : AL + PE, OPP + PE, NY + PE and other sealable papers
Operating Speed : 40-80 packs/minute
Supply Voltage : 220/380, 1ph/3ph, neutral 50 Hz/60 Hz
Power Requirement : 1.4 kVA
4. AW 6035 Jumbo
aw 603 jumbo1 Mesin Pengemas Makanan Ringan Vertical Filling AW 6035 sr
Product : Powder, Seed, Granule, Chips etc
Seal Type : Centre seal (pillow pack)
Machine Type : Vertical pouch with fix bag former size and volumetric cup system
Seal Dimension : W : 50-160 mm, L : 50-200 mm
Product Weight : Up to 500 gram
Machine Dimension : W x L x H = (765 x 710 x 1930)mm
Packaging Material : AL + PE, OPP + PE, NY + PE and other sealable papers
Operating Speed : 40-70 packs/minute
Supply Voltage : 220/380V, 1ph/3ph, Neutral 50 Hz/60 Hz
Power Requirement : 1.6 kVA
–
Mesin untuk packing kardus / cartoon
| Model : FXJ 6050
Conveyor Speed : 0 – 20 m / min Model : FXJ 5045 Conveyor Speed : 0 – 20 m / min |
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
PAD PRINTING AND CODING MACHINE
Fungsi : mesin printer yang bisa digunakan untuk membuat kode dan tanggal pada produk.
Spesifikasi Mesin
| Model : DDYM-520A Kecepatan printing : 0-60 kali / menit Printer hight : 0-300 mm Mould size : 85×175 mm Berat mesin : 40 kg Ukuran mesin : 60×38x61 cm |
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
Mesin Pengemas Vacuum untuk mengemas produk (makanan / barang) dengan kemasan yang bebas udara, sehingga produk tersebut lebih awet, hiegenis dan praktis.
Spesifikasi Mesin
| Model : DZ-400T ( One Seal ) Power supply :110V 220-240V/50-60Hz Power consumption : 750 W Chamber size : 440 x 440 x 115 mm Sealer size : 400 x 10 mm Exhausment of pump : 20 m 3 / hr Vacuum pressure : 0.66 Kpa Machine size : 660 x 590 x 680 mm Machine weight : 102 Kg Model : DZ 400 ( Double Seal ) Power supply : 110V 220-240V/50-60Hz Model : DZ 500 Power Consumtion : 850 W |
JAMINAN KUALITAS
–
JAMINAN KEPUASAN
Mesin untuk mengemas packing gelas minuman yang biasa untuk es, cock tail, dan minuman lain yang biasa di jual di mall, restoran. Untuk tipe semi otomatis sangat mudah dan efektif. Mesin ini sangat cocok untuk usaha franchise
Spesifikasi Mesin
Model : FRG 2001 C
Power supply : 220 – 240 V/50-60 Hz 1 Phase
Power consumption : 300 W
Sealing speed : 400 – 500 cup / hari
Machine size : 450 x 490 x 700 mm
Machine weight : 40 kg
